GENERAL SPECIFICATIONS
Functions
PRINTER SPECIFICATIONS
Print Resolution
Up to 4800¹ x 1200 dpi
Print Technology
2 FINE Cartridges (Black and Colour)
Refillable ink tank printer with 2pl (min.) ink droplet size
Mono Print Speed
Approx. 8.8 ipm¹
Colour Print Speed
Approx. 5.0 ipm¹
Photo Print Speed
Borderless 10x15cm : Approx. 60 seconds¹
Borderless Printing
Yes (A4, Letter, 20x25cm, 13x18cm, 10x15cm)
CARTRIDGES AND YIELDS
Standard Ink Cartridges
GI-590 (PGBK)
GI-590 (C)
GI-590 (M)
GI-590 (Y)
Cartridge Yield (Plain paper)
A4 colour documents printing¹
Black: 6000 pages*
Colour: 7000 pages*
* Estimated supplemental yield
PAPER SUPPORT
Paper Types
Plain Paper
High Resolution Paper (HR-101N)
Photo Paper Plus Glossy II (PP-201)
Photo Paper Pro Luster (LU-101)
Photo Paper Plus Semi-gloss (SG-201)
Glossy Photo Paper "Everyday Use" (GP-501)
Matte Photo Paper (MP-101)
Envelope
Maximum Paper Input
Rear tray: Max. 100 sheets (plain paper)
Paper Sizes
A4, A5, B5, 10x15cm, 13x18cm, 20x25cm, Envelopes (DL, COM10), Letter, Legal
Paper Weight
Plain paper: 64 - 105 g/m²
Canon photo paper: up to 275 g/m²
SCANNER SPECIFICATIONS
COPIER SPECIFICATIONS
INTERFACE
Display Type & Size
No display
Interface Type - PC / Mac
Hi-Speed USB (B Port)
Compatible Memory Cards
n/a
SOFTWARE
Supported Operating Systems
Windows 10
Windows 8.1 (including Windows 8.1 Update), Windows 8
Windows 7, Windows 7 SP1
Windows Vista SP2
Windows XP SP3 (32 bit only)
Note: For Windows, .NET Framework 4 or .NET Framework 4.5 is
required.
For Windows XP, XPS Essentials Pack is required.
Mac OS X v10.7.5 to Mac OS X v10.10
Minimum System Requirements
Windows: 3.1GB disk space, Internet Explorer 8
Mac: Internet connection, 1.5GB disk space, Safari 5
Display: 1024 x 768 XGA
Software Included
Printer Driver
My Image Garden with Full HD Movie Print¹
Quick Menu
Easy-WebPrint EX (download)²
PHYSICAL FEATURES
Weight
approx. 4.3 kg
Dimensions (W x D x H)
approx. 445 x 330 x 135 mm
Acoustic Noise Levels
approx. 46.5dB(A)¹
Operating Temperature
5-35°C
Operating Humidity
10-90%RH (no dew condensation)
Power Source
AC 100-240V, 50/60Hz
Power Consumption
Off: Approx. 0.4 W
Standby (connected to PC via USB): Approx. 0.8 W
Standby (all ports connected): Approx. 0.8 W
Time to enter Standby mode: 2 minutes
Printing: Approx. 12 W¹
Отказ от ответственности
All specifications subject to change without notice
Print speed may vary depending on system configuration, interface, software, document complexity, print mode, page coverage, type of paper used etc.
Ink yield may vary depending on texts/photos printed, applications software used, print mode and type of paper used. For yield information see www.canon-europe.com/ink/yield
All brand and product names are trademarks of their respective companies.
Microsoft, Windows and the Windows logo are trademarks, or registered trademarks of Microsoft Corporation in the United States and/or other countries.
Примечания
¹ Ink droplets can be placed with a minimum pitch of 1/4800 inch
¹ A4 document print speed on plain paper is measured based on average of ESAT in Office Category Test of ISO/IEC 24734 standard.
¹ A4 document print speed on plain paper is measured based on average of ESAT in Office Category Test of ISO/IEC 24734 standard.
¹ Photo print speed is based on default driver setting using ISO/JIS-SCID N2 standard on Canon Photo Paper Plus Glossy II and does not take into account data processing time on host computer.
¹ Page yield is the estimated value based on Canon individual test method using the ISO/IEC 24712 chart & continuous printing simulation with the replacement ink bottles after initial setup. Page yields are not to be combined.
¹ Full HD Movie Print is available for MOV and MP4 movie files
created by select Canon digital cameras and camcorders. Requires
installation of software bundled with Canon video or digital
camera, from which the movie was captured. MOV files require:
ZoomBrowser EX / ImageBrowser (version 6.5 or later), MP4 files
require: ImageBrowser EX (version 1.0 or later).
² Easy-WebPrint EX requires Internet Explorer 8 or later
¹ When printing ISO/JIS-SCID N2 pattern on 10x15cm Photo Paper Plus Glossy II using default settings.
¹ When copying ISO/JIS-SCID N2 (printed by inkjet printer) on A4 size plain paper using default settings.
